Product Description

Features

  • Professional, Baltic birch construction with wear resistant polymer coating
  • 117dB sustained output, 120dB peak with very high dynamic range
  • Compact cabinet design allows for use as front fill or under balcony applications
  • Wide dispersion 100° H x 100° V horn
  • Revolutionary new passive delay line
  • 1.75″ (44 mm) diaphragm compression driver with complex geometry phase plug for higher output, exceptionally low distortion, extended frequency response and neodymium magnetic motor structure
  • 6″ woofer with Low Inductance Lightweight voice coil technology and neodymium motor structure dramatically increases force and lowers distortion
  • Proprietary top handle design for simplified handling and carrying, integrates one M10 suspension point, OmnimountTM bracket point and four M6 points
  • Additional side and bottom M10 points for flexible bracket, rigging and installation options
  • “Top-hat” pole mount fitted at the base of the cabinet

Applications

Specifically designed as a passive loudspeaker for reproduction of recorded music in small areas

  • Suitable in Fixed installations as full range stand-alone or with subwoofers
  • Excellent peripheral reinforcement for main KV2 systems
  • Portable PA for Multi-Media applications
  • Compact floor monitoring solutions
  • Domestic and Professional studio monitoring

Product code

  • KVV 987 206 – ESD6
Please follow and like us:
More Info

Additional Information

Max SPL Long-term

117dB

Max SPL Peak

120dB

-3dB Response

68Hz to 20kHz

-10dB Response

62Hz to 22kHz

Recommended Power

175W

Sensitivity

92dB

Impedance

16Ω

Crossover Point

2.0kHz

High Horn Coverage Horizontal / Vertical

100° x 100°

Throat Exit Diameter / Diaphragm Size

1" / 1.75"

Acoustic Design

Front Loaded, Bass Reflex

Woofer Size / Voice Coil Diameter / Design

6" / 1.75"

Diaphragm Material

Epoxy Reinforced Cellulose

Magnet Type

Neodymium

Protection

RMS Limiter

Speaker Input

2x Neutrik Speakon®, Terminal Block

Cabinet Material

Baltic birch

Handles

1

Pole Mount

35 mm

Color

"Orange peeled" Matt Black or any RAL

Height

390 mm (15.35")

Width

220 mm (8.66")

Depth

240 mm (9.45")

Weight

9.5 kg (20.9lbs)
