Product Description
Features
- Professional, Baltic birch construction with highly resistant polymer coating
- Four full length pieces of fly-track (two per side) and one five point pull back piece on the rear of the cabinet
- Very High Definition low frequency reproduction
- 143dB sustained output / 146dB peak (using 4 units of VHD 2.16)
- High acoustic loading via twin asymmetrical chambers
- Two 15″ low frequency drivers with 4″ (100 mm) inside/outside, epoxy baked, high temperature voice coil assembly and neodymium magnetic structures
- Proprietary side handles (6) for simplified handling and carrying
- High impact low friction feet, allowing lock- in to other VHD cabinets and easy cabinet movement
- Front locking aluminium VHD wheel boards with wraparound hardwood bumpers
- Weather proofing option and special paint finishes available on request
Applications
Specifically designed to accompany the VHD2.0 and VHD1.0 as a true full range high output system for live performance and music
- Hire and Production
- Concert venues
- Large Theatres
- Scalable into multiple large systems
- Fixed installation
Product code
- KVV 987 142 – VHD2.16
Please follow and like us:
Additional Information
| Max SPL Long-term | 143dB (4x VHD2.16) |
|---|---|
| Max SPL Peak | 147dB (4x VHD2.16) |
| -3dB Response | 37Hz to 130Hz |
| -10dB Response | 32Hz to 130Hz |
| Impedance | 8Ω |
| Crossover Point | 100 to 130Hz |
| Acoustic Design | Twin Asymmetrical loading |
| Low Frequenzy Amplifier Requirement | 1600W /2x VDH2.16 (VHD3200 amp.) |
| Woofer Size / Voice Coil Diameter / Design | 2x 15" / 4" / Inside Outside |
| Diaphragm Material | Epoxy Reinforced Cellulose |
| Magnet Type | Advanced ventilated neodymium |
| Speaker Input | AP4 male |
| Speaker Output | AP4 female |
| Cabinet Material | Baltic birch |
| Handles | 6 |
| Color | "Orange peeled" Matt Black or any RAL |
| Height | 600 mm (23.62") |
| Width | 700 mm (27.55") |
| Depth | 750 mm (29.52") |
| Weight | 65 kg (143lbs) |
